Explain the light switch plan drawing

  • Erstellt am 2017-03-21 21:02:09

jamal-01

2017-03-21 21:02:09
  • #1
Hello friends,
what do these symbols mean?
The front door opens to the left, the symbols are on the right.
What is meant by this?

Do I understand it correctly,
Top symbols light switch stairwell/hall upstairs.
Middle switch light switch hallway/corridor
Bottom switch for outside light

Please advise


Robbaut

2017-03-21 21:08:06
  • #2
Two "flags" means two-way switching, one is a normal switch


jamal-01

2017-03-21 21:16:15
  • #3
what does that mean now?


RobsonMKK

2017-03-21 21:20:11
  • #4


Robbaut

2017-03-21 21:37:11
  • #5
Wikipedia explains the two-way switch very well... Nothing more can be deduced from the symbol, i.e. which lamp is controlled by which switch should have been noted or remembered by the electrician.


jamal-01

2017-03-21 22:04:29
  • #6
But they are lamps, right?
